PixelBro84 Configurator

Configure your PixelBro84 and test its LEDs before saving to the controller.

Not connected

This browser does not support Web Serial.Open this page in desktop Chrome or Edge to connect.

Device statusConnect your PixelBro84 to begin.

Configuration

FW —

Cyclotron LEDs

GPIO3 output chain

LED StyleOnly the center LED in each window is illuminatedLED controllerSelect RGB LED typeColor orderChange this if red and green are swappedData rateMost modern pixels use 800 kHz

Cake LEDs

GPIO27 output chain

LED count1–64 addressable pixelsLED controllerSelect RGB LED type (Default: WS2812B)Color orderChange this if red and green are swappedData rateMost modern pixels use 800 kHz

Bypass lid detectionKeep the lid output active regardless of the sensor

Animation

Cyclotron LEDs

Animation

LED Color

EffectChoose the visual treatment for the cyclotron chaseTimingInput gates start/stop in either timing modeSynchronized speedCyclotron rotations per input rotation

Reverse cyclotron directionRun the cyclotron chase in the opposite direction

Cake LEDs

Animation

LED Color

EffectChoose the visual treatment for the Cake chaseTimingLock to the outer lights or use a fixed durationSynchronized speedCake rotations per cyclotron rotationStart offset0 means the first physical LED

Reverse cake directionRun the circular chase in the opposite direction

LED Testing

Test selected effect runs the cyclotron and Cake animations without requiring incoming WS2812 data. Synchronized preview uses a 250 ms phase clock; free-running preview uses the selected rotation settings.

Cyclotron LEDs

Test each cyclotron window; puck styles light the center pixel in that window with the selected color.

Cake LEDs

Select a position to identify physical LED 1 and verify the configured color order.
